Graphtec GL-860
$ 2,195.00 USD

High-performance 200-channel data logger with 7” color LCD, USB and Ethernet interfaces, isolated inputs, and flexible sampling rates—ideal for multi-channel voltage, temperature, and environmental monitoring with precision and reliability. IMPORTANT NOTE: Input terminal must be ordered separately (unless user already owns an input terminal they plan to use). Choose from B-563, B-563SL, B-563SL-30 or B-565

No items found.
Show all photos
No items found.

Graphtec GL-860

$ 2,195.00 USD
High-performance 200-channel data logger with 7” color LCD, USB and Ethernet interfaces, isolated inputs, and flexible sampling rates—ideal for multi-channel voltage, temperature, and environmental monitoring with precision and reliability. IMPORTANT NOTE: Input terminal must be ordered separately (unless user already owns an input terminal they plan to use). Choose from B-563, B-563SL, B-563SL-30 or B-565
qty
FREE Ground USA Shipping
Product Demo
Product Overview
Product Specifications
Tech Specifications
Access the Product Manual
Access the Brochure

Product Demo

Product Overview

  • Data logger with 7-inch Color LCD Display
  • 4 digital channels
  • 4 alarm outputs
  • 8GB internal memory
  • SDHC card slot (max 32GB)
  • USB & Ethernet PC interface
  • Expandable to 200 channels
  • Operates under AC power adapter included
  • Requires B-573 for battery operation, sold separately
  • 8GB internal memory, SD card (sold separately) up to 32GB
  • 20mV to 100 Vdc & 1-5 Vdc full scale ranges
  • Calibration Certificate, required and sold separately
  • Input terminal sold separately (recommended B-565)

Product Specifications

Tech Specifications

Dataloggers / Data Acquisition/Dataloggers for Environmental Variables/Humidity Dataloggers Template

Min Temperature 3000 F
Type E, J, K, RTD, S, T
Input Source External Probe
Inputs/Channels Other
SAMPLE RATE/Intervals 5ms-1h
LCD Screen Yes
Software Included Yes
RH 100 %
Power Source AC Line

‍

Dataloggers / Data Acquisition/Voltage Datalogger Template

Max Voltage  100 V
Min Voltage 20 mV (0.02 V)

‍

Test Equipment General Attributes

Interfaces I/O LAN / Ethernet, USB
Storage Internal Memory, SD Card
Data Logging Yes
